Platform
Moterra
Neo LT
Model Name
Moterra LT Carbon 2
Model Code
C25552U
Frameset
Frame
Moterra Carbon Front Triangle, SmartForm C1 Alloy Swingarm,
165mm travel, Proportional Response Tuned Suspension, removable downtube
battery, alloy skid plate, 55mm chainline, internal cable routing, 148x12mm
thru-axle, UDH hanger, post mount brake, 1.5” – 1.8” tapered headtube, 18mm
two-bolt kickstand mount
Fork
RockShox Zeb Select, Charger RC, 170mm, DebonAir, 15x110mm,
44mm offset
Headset
Acros integrated sealed bearing, tapered
Rear Shock
RockShox Deluxe Select+, Coil, 2-Pos mode adjust, adjustable
rebound
E-System
Drive Unit
Bosch Performance Line CX 250W
Battery
Bosch PowerTube, 750Wh
Charger
Bosch 4A
Display
Bosch Kiox 300 w/ LED remote
Drivetrain
Rear Derailleur
Shimano XT
Shifters
Shimano SLX, 12-speed
Chain
Shimano SLX, 12-speed
Crank
FSA Bosch E-bike w/ 55mm chainline, 160mm, 34T
Rear Cogs
Shimano SLX, 10-51, 12-speed
Brakes
Brakes
SRAM Code R hydraulic disc, 220/200mm centerline rotors
Brake Levers
SRAM Code R hydraulic disc
Wheels
Rims
WTB ST i30 TCS, 32h, tubeless ready
Spokes
Stainless Steel, 14g
Tire Size
2.6
Wheel Size
29
Hubs
(F) Formula 15x110mm thru-axle / (R) Shimano MT410, 12x148mm
thru-axle
Tires
(F) Maxxis Assegai, 29x2.6", 3C, EXO+, tubeless ready,
(R) Maxxis DHR II, 27.5x2.6", 3C, EXO+, tubeless ready
Front Tire
Maxxis Assegai, 29x2.6", 3C, EXO+, tubeless ready
Rear Tire
Maxxis DHR II, 27.5x2.6", 3C, EXO+, tubeless ready
Components
Handlebar
Cannondale 3 Riser, 6061 Alloy, 25mm rise, 8° sweep, 5°
rise, 800mm
Stem
Cannondale 2, 6061 Alloy, 35mm, 0°
Grips
Fabric FunGuy
Saddle
Fabric Scoop Shallow Sport, steel rails
Seatpost
Cannondale DownLow Dropper, internal routing, 31.6, 125mm
(S), 150mm (M-XL)
Extra
Extra 1
Pre-installed light cable
